产品规格
| Cutting Diameter (DC) | 3.15″ | Master Insert Identification (MIID) | GSFN 3 |
| Cutting Item Count (CICT) | 6 | 应用 | | T型槽 | 侧向开槽 | 切断 | 槽铣加工 | |
| Peripheral Effective Cutting Edge Count (ZEFP) | 6 | Rotational Speed Maximum (RPMX) | 1000 Rev/min |
| Cutting Depth Maximum (CDX) | 0.63″ | Tool Type | Slitting cutters |
| Hub Diameter (DHUB) | 1.57″ | 测量方式 | Inch |
| Hub Thickness (THUB) | 0.09″ | 刀体材质 | Steel |
| Cutting Width Maximum (CWX) | 0.14″ | Connection Code Machine Side (CCMS) | Disk type |
| Cutting Width Minimum (CWN) | 0.11″ | 单位 | I |
产品特性
| 系列描述 | 锯片铣刀，夹持自夹式铣刀片 | 系列名称 | SGSF |
| 备注 | Only the K type cutters feature 4 driving holes around the central hole; they can be driven by the R drive shanks Refer to SW/S drive shanks and R driving flange set Maximum RPM may not be exceeded | 品牌 | Iscar |
| COO | Israel |
Shipping Info
包装重量
0.2998
名字
Disc w/Hole Indexable Slotting Cutters
系列名称
SGSF
品牌
Iscar
