产品规格
| Cutting Diameter (DC/DCX) | 32 mm | Functional Length (LF) | 250 mm |
| Cutting Diameter (DC) | 32 mm | Tool Type | 90° indexable endmills |
| Cutting Item Count (CICT) | 3 | Flute Count (NOF) | 3 |
| Depth of Cut Maximum (APMX) | 14.3 mm | Coolant Supply Property (CSP) | External |
| Overall Length (OAL) | 250 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| 柄部形式 | Round | Cutting Direction (HAND) | Right Hand |
| Ramping Angle Maximum (RMPX) | 5.3 Degrees | 测量方式 | Metric |
| 应用 | | 坡走铣 | 方肩铣 | 槽铣加工 | 沉孔铣削 | 面铣 | | 刀体材质 | Steel |
| Connection Diameter Machine Side (DCONMS) | 31 mm | Connection Code Machine Side (CCMS) | Cylindrical |
| Master Insert Identification (MIID) | ADKT 1505PDTR | 单位 | M |
| Head Length (LH) | 30 mm |
产品特性
| 系列描述 | 90°主偏角立铣刀，夹持铣刀片HM90 ADKT-1505… | 系列名称 | HM90 E90AD-15 |
| 备注 | For adaptation, click on More Info Thinner insert ADM. 1503.. mounted on TSP-15R seat | 品牌 | Iscar |
| COO | Israel |
Shipping Info
包装重量
1.5540
名字
Indexable End Mills
系列名称
HM90 E90AD-15
品牌
Iscar
