产品规格
| 适用材料 | | 钢 | 不锈钢 | 高温合金 | | Maximum Feed per Tooth (fz(max)) | 0.4 mm/tooth |
| 应用 | | 大进给铣削 | 带斜面或倒角方肩铣削 | 面铣 | | Cutting Direction (HAND) | Right Hand |
| Insert Length (INSL) | 6.43 mm | 切削刃材质 | Carbide |
| Corner Radius (RE) | 1.6 mm | Tool Type | Double sided Inserts |
| Depth of Cut Maximum (APMX) | 3 mm | Minimum Feed per Tooth (fz(min)) | 0.08 mm/tooth |
| Insert Thickness (S) | 7.15 mm | 切削刃数量 | 12 |
| Insert Included Angle (EPSR) | 120 Degrees | 测量方式 | Metric |
| 涂层 | AlTiN+TiN | 刀体材质 | Carbide |
| 等级 | IC830 | 单位 | M |
产品特性
| 系列描述 | 双面六边形刀片，带12个切削刃 | 系列名称 | H1200 HXCU 0606 |
| 备注 | TR-for steel and cast iron, HPR-for stainless steel and high temperature alloys | 品牌 | Iscar |
| COO | Israel |
Shipping Info
包装重量
0.0148
名字
Milling Indexable Inserts
系列名称
H1200 HXCU 0606
品牌
Iscar
