产品规格
| 适用材料 | | 钢 | 不锈钢 | 铸铁 | 硬材料 | 高温合金 | | 涂层 | AlTiN |
| 应用 | | 倒角 | 埋头螺钉孔加工 | 带斜面或倒角方肩铣削 | 钻削 | 钻铣 | | 等级 | IC900 |
| Cutting Diameter (DC) | 5 mm | 柄部形式 | Round |
| Usable Length (LU) | 9.3 mm | Tool Type | Solid chamfering endmills |
| Flute Count (NOF) | 2 | 测量方式 | Metric |
| Depth of Cut Maximum (APMX) | 3.61 mm | 刀体材质 | Carbide |
| Overall Length (OAL) | 50 mm | Connection Code Machine Side (CCMS) | Cylindrical |
| Connection Diameter Machine Side (DCONMS) | 5 mm | 单位 | M |
| 切削刃材质 | Carbide |
产品特性
| 系列描述 | 整硬倒角钻 | 系列名称 | ECD-S2 |
| COO | Israel | 品牌 | Iscar |
Shipping Info
包装重量
0.0170
名字
Chamfer Mills
系列名称
ECD-S2
品牌
Iscar
