产品规格
| Cutting Diameter (DC) | 0.812″ | Overall Length (OAL) | 3.54″ |
| Usable Length (LU) | 0.81″ | Coolant Supply Property (CSP) | Coolant Thru |
| 应用 | | 钻削 | 钻铣 | | 测量方式 | Inch |
| Connection Diameter Machine Side (DCONMS) | 1″ | Master Insert Identification (MIID) | SOMX 07 |
| Tool Type | indexable head drills | 刀体材质 | Steel |
| Protruding Length (LPR) | 1.26″ | 十进制 | 0.812″ |
| Shank Length (LS) | 2.28″ | Shank Diameter Tolerance (TCDMM) | h6 |
| Functional Length (LF) | 1.2″ | 单位 | I |
产品特性
| 系列描述 | 钻铣多功能刀具，可用于插铣，方肩铣，槽铣，型腔铣，扩孔，锪面和仿形等应用。 | COO | Israel |
| 备注 | Hole tolerance: +.006/-.002 in average conditions applied. It can be higher or lower according to machine and tooling conditions. Intermediate sizes may be obtained by shifting the drill center along the lathe X-axis, or by using eccenter sleeves (see page ..) in drill rotating applications. |
Shipping Info
包装重量
0.5975
